Inner rubber layer：Neoprene synthetic rubber, suitable for hydraulic oil that can be degraded
Reinforcement layer：super-strong high-flex steel wire wound in four layers, pulse ≥ 1 million times
outer layer： standard:no-skive abrasion, weather resistant synthetic rubber.
AR cover: no-skive, highly abrasion, weather resistant synthetic rubber.
SAR cover: super abrasion, weather resistant UHMWPE.
Temperature range：-40°C to +121°C (-40°F to +250°F)

Inner rubber layer：Neoprene synthetic rubber, suitable for hydraulic oil that can be degraded
Reinforcement layer：two braids of high tensile steel wire (1/4"-5/16"), impulse2500,000 cycles.
four plies of spiraled high tensile steel wire (3/8"-1 1/4"), impulse21,000,000 cycles.
six plies of spiraled high tensile steel wire (1 1/2"-2"), impulse21,000,000 cycles.
Outer layer：standard:abrasion, weather resistant synthetic rubber.
AR cover: highly abrasion, weather resistant synthetic rubber.
SAR cover: super abrasion,weather resistant UHMWPE
Temperature range：-40C-+100C(-40F-+212°F)
-40°C~+121°C(-40F-+250°F)

Inner rubber layer：Neoprene synthetic rubber, suitable for hydraulic oil that can be degraded
Reinforcement：Four layers of steel wire winding (1/4"‒1"), pulse ≥1 million, six layers of steel wire winding (1 1/4"‒2"), pulse ≥1 million times
Outer layer：standard;abrasion, weather resistant synthetic rubber.
AR cover: highly abrasion, weather resistant synthetic rubber.
SAR cover: super abrasion,weather resistant UHMWPE.

Temperature range：-40°C to +121°C (-40°F to +250°F)

Inner rubber layer： NBR or CR synthetic rubber, suitable for biodegradablehydraulic fluids.
Reinforcement layer：one or two layers of steel wire weaving (1/2" ‒3/4"), pulse ≥ 300,000 times, four layers of steel wire winding (1" ‒ 2"), pulse ≥ 1 million times
Outer layer：standard: no-skive abrasion, weather resistant synthetic rubber.
AR cover: no-skive, highly abrasion, weather resistant synthetic rubber.
SAR cover: super abrasion, weather resistant UHMWPE.
Temperature range：-40℃ to +100℃ (-40℉ to +212℉) -40℃ to +121℃ (-40℉ to +250℉)

Inner rubber layer： NBR or CR synthetic rubber, suitable for biodegradablehydraulic fluids.
Reinforcement layer：one or two layers of steel wire weaving (1/4" ‒3/8"), pulse ≥300,000 times four layers of steel wire winding (1/2"‒2"), pulse ≥1 million times
Outer layer：standard: no-skive abrasion, weather resistant synthetic rubber.
AR cover: no-skive, highly abrasion, weather resistant synthetic rubber.
SAR cover: super abrasion, weather resistant UHMWPE.
Temperature range：-40℃ to +100℃ (-40℉ to +212℉) -40℃ to +121℃ (-40℉ to +250℉)
